Medical Imaging 3.5 Inch Display TUYOU 1080P Portable Reusable Endoscope Camera For Bronchoscopy, ENT,pediatric urology And Pet Inspection

Our cutting-edge endoscope medical imaging system is designed to seamlessly integrate with a wide range of endoscopes, including otoscopes, sinusoscopes, laryngoscopes, laparoscopy machines, arthroscopes, and cystoscopy cameras. This versatile system is engineered to support a variety of surgical procedures, from ENT diagnostics to urological and gynecological interventions.

Equipped with a medical-grade monitor that delivers exceptional image clarity and color accuracy, our medical endoscope camera ensures precise visualization for optimal surgical outcomes. Whether you’re performing minimally invasive surgeries or complex diagnostic examinations, this system provides the flexibility and reliability required for modern medical practices.

Compatible with both rigid and flexible endoscopes, our system offers a comprehensive solution for diverse clinical needs, empowering healthcare professionals to deliver superior patient care.Medical Imaging 3.5 Inch Display TUYOU 1080P Portable Reusable Endoscope Camera For Bronchoscopy, ENT,pediatric urology And Pet Inspection

Recommended productsTUYOU 3.5 Inch Reusable Flexible Handheld Endoscope Medical System For ENT Laryngoscope Otoscope And Pet Exams

Medical Imaging 3.5 Inch Display TUYOU 1080P Portable Reusable Endoscope Camera For Bronchoscopy, ENT,pediatric urology And Pet Inspection

Product Parameters

Specifications
Model#	TU-HSB320	TU-HSB260	TU-HSB120
Working Channelinner diameter	3.2mm+10%	2.6mm+10%	1.2mm+10%
Tube outer diameter	5.8mm+10%	4.8mm+10%	2.8mm+10%
Screen rotation Angle		Left Right180° Up160        Down30°
Tube Length		600mm
internal storage		16GB

Medical Imaging 3.5 Inch Display TUYOU 1080P Portable Reusable Endoscope Camera For Bronchoscopy, ENT,pediatric urology And Pet Inspection

Product performance description

• Diameter: 2.8mm or 4.8mm optional
• It can be bent up and down from 180 to 270 degrees, which can meet the observation in the direction of the whole field of view.
• In the 4.8mm small diameter, the working channel is as large as 2.6mm; in the 2.8mm ultrasmall diameter, the working channel for injection, suction can still be 1.2mm. Both models can be used to realize biopsy, water vapor injection, suction, sputum suction, foreign body extraction, etc.
• Support 300mm~1000mm length customization to meet various customization needs.
• Screen size: 3.5 - inch or 12.1 - inch high - definition optional, and support output to a larger screen through HDMI.

TUYOU 3.5 Inch Reusable Flexible Handheld Endoscope Medical System For ENT Laryngoscope Otoscope And Pet Exams

 Features

• The ALL - in - ONE model is easy to use for diagnosis and treatment. It features working channels and suction functions.
• The 3.5 - inch IPS high - definition screen can be adjusted up and down with one hand. A fully - charged lithium battery can last for 4 hours.
• It supports photo and video taking. Images can be output and externally connected to a monitor, facilitating teaching, image storage, and medical record filing.
• It has a FOV120° field of view angle and can be connected to various types of disposable laryngoscope blades.
• The handle design is ergonomic.

Medical Imaging 3.5 Inch Display TUYOU 1080P Portable Reusable Endoscope Camera For Bronchoscopy, ENT,pediatric urology And Pet Inspection

FAQ

Q:Are you a factory or a trading company?

A: We are a Chinese medical imaging instruments manufacturer. All the products are made of our workers, we have 4 production lines and R&D team.

Q: Where are you ?
A: Our adress is buliding 3,Yunchuang Valley Southern Pacific, Fenghuang District, Shenzhen City, Guangdong Province, China.You are welcomed to visit our factory.

Q: Can you accept OEM?
A: Yes, we offer "TUYOU" brand to you. But if you need, we can also offer OEM service.

Q: What's your deliver time?
A: It will be delivered within 7 working days upon your payment; Samples are ready-made.

Q: What is the warranty?
A: The free warranty is three years. If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
